Merlyn GSQ1480HL 1400 x 800 Left Offset Quadrant Enclosure

The Merlyn GSQ1480HL is an Arysto Ten one-door offset quadrant shower enclosure, handed left, for a 1400 x 800 mm footprint. It gives a wider offset shape than a square quadrant while keeping a single door opening.

It suits domestic bathrooms, whether you are fitting a new enclosure or replacing an existing offset quadrant of the same size. The recess adjustment is 1370–1385 mm on the long side and 770–785 mm on the short side, with an overall height of 2000 mm.

The enclosure uses 10 mm clear glass in a polished chrome finish. A moving panel, two fixed panels and a 460 mm door opening in the recess are set out for this exact code.

Key Features

• Arysto Ten one-door offset quadrant, code GSQ1480HL
• Left-handed
• Nominal size 1400 x 800 mm
• Recess adjustment 1370–1385 mm and 770–785 mm
• 2000 mm high
• 10 mm clear glass
• Polished chrome finish
• Door opening 460 mm in the recess
• Moving panel 615 mm; fixed panels 485 mm and 845 mm
• Lifetime guarantee

Benefits

• Offset footprint uses a 1400 x 800 mm space rather than a square quadrant
• Left-hand door matches a left-opening layout
• Recess adjustment allows a small amount of fitting tolerance on both walls
• 2000 mm height suits a standard full-height enclosure install
• 10 mm glass gives a substantial glazed screen
• Clear glass keeps the shower area light
• Polished chrome finish suits typical chrome bathroom brassware
• Lifetime guarantee covers the enclosure as stated by Merlyn

Technical Specifications

• MPN: GSQ1480HL
• Model: ARYSTO Ten
• Size: 1400 x 800 mm
• Adjustment in recess: 1370-1385 / 770-785 mm
• Height: 2000 mm
• Glass thickness: 10 mm
• Glass finish: Clear
• Colour: Polished Chrome
• Handing: Left handed
• Door opening in recess: 460 mm
• Moving panel A: 615 mm
• Fixed panel B: 485 mm
• Fixed panel C: 845 mm
• Guarantee: Lifetime

What’s in the Box?

1 x Merlyn GSQ1480HL Arysto Ten left-hand offset quadrant enclosure
