Wirquin 16110201) Jollyfill 1/2″ BSP Telescopic Bottom Inlet Float Valve Brass Thread 10120687 (old code

The Jollyfill range from Wirquin is a user friendly WRAS approved professional range and features a delayed action system for greater water saving, compact and space saving, easily adjusted height, fast filling and has an ultra quiet fill. This inlet valve is also suitable for low and high operating pressure at 0.1 up to 16 bar pressure and is resistant to peaks of pressure of up to 20 bar.

The Jollyfill inlet valve also features an anti-siphoning design, eliminates water hammer and is quick closing. New Model which has the new Air Gap to comply with water regulations (replaces 10120687).

Key Features

• WRAS approved
• 1/2” BSP brass inlet
• Suitable for low or high pressure
• Range from 0.1 up to 16 bar
• Water saving delayed action
• Telescopic height from 250mm to 390mm
• Ultra quiet and anti-syphoning
• Eliminates water hammer

Specifications

• 1/2″ BSP brass thread
• Telescopic adjustment 250-390 mm
• Operating pressure 0.1-16 bar (peaks to 20 bar)
• WRAS approved
• Manufactured in Romania

Applications

Bottom entry inlet valve for most toilet cisterns.

What’s in the box

1 x Jollyfill telescopic bottom inlet valve.
