Tucson 771960 Equinox 3 Bar Universal Head Twin Impeller Shower Pump 22mm

Suitable for both positive and negative head installations, the Equinox 3 Bar pump is ideal for properties suffering from low water pressure, including loft conversions, en-suite bathrooms, rainfall shower installations, and homes where outlets are located below the cold water storage tank. Advanced flow-switch technology enables reliable operation even where natural flow is limited.

Manufactured with a robust CW617N brass pump body for long-term durability, the pump operates quietly at less than 66dB and includes flexible anti-vibration hoses and a vibration-dampening base mat to minimise noise transmission. With a maximum head of 32 metres and a flow rate of up to 40 litres per minute, it provides a powerful boost for demanding domestic shower and bathroom applications.

Key Features

• Universal head (negative head) shower pump suitable for low-flow installations.
• Powerful 3.0 bar pressure boost for improved shower performance.
• Twin impeller technology boosts hot and cold supplies equally.
• Suitable for positive and negative head gravity-fed systems.
• Maximum flow rate of 40 litres per minute.
• Quiet operation at less than 66dB.
• Durable CW617N brass construction.
• Ideal for rainfall showers, family bathrooms and multi-outlet systems.
• Includes anti-vibration base mat and flexible connection hoses.
• Supplied with a 3-year manufacturer warranty.

Specifications

• Brand: Tucson
• MPN: 771960
• EAN: 5391536249632
• Range: Equinox
• Pump Type: Twin Impeller Universal Head Shower Pump
• Operating Pressure: 3.0 Bar
• Maximum Head: 32m
• Flow Rate: 40L/min
• Maximum Working Pressure: 10 Bar
• Noise Level: <66dB
• Weight: 11.5kg
• Power Cable: 1.5m Pre-Wired Cable with 3-Pin Plug
• Warranty: 3 Years

What’s in the Box

• 1 x Tucson Equinox 3 Bar Universal Head Twin Impeller Shower Pump
• 4 x 22mm Stainless Steel Flexible Braided Hoses
• 4 x Integrated Isolating Valves
• 1 x Anti-Vibration Base Mat
• 1 x Pre-Wired Power Cable with 3-Pin Plug
• Installation Instructions
