Merlyn S10SW600H 600mm 10 Series Shower Wall Panel

The Merlyn S10SW600H is a 10 Series wetroom shower wall panel, 600 mm wide, supplied with a wall profile and a straight stabilising bar. It is made from 10 mm toughened clear glass with chrome fittings.

It suits a recess or a corner, and can be used in a wetroom or over a shower tray. Handing is reversible, so the same panel can be fitted left or right.

Glass height is 2000 mm, rising to 2015 mm including the rail. Tray finish adjustment for this size is 575–590 mm.

Key Features

• 600 mm 10 Series shower wall panel
• Includes wall profile and straight stabilising bar
• 10 mm toughened clear glass
• Chrome finish
• Glass height 2000 mm; 2015 mm including the rail
• Tray finish adjustment 575–590 mm
• Reversible handing
• Suitable for a recess or corner
• Suitable for wetroom and shower tray use
• Lifetime guarantee

Benefits

• Gives a fixed glass screen without a hinged door
• Wall profile and stabilising bar are included
• Clear 10 mm glass suits a typical wetroom look
• Reversible handing avoids ordering a left- or right-hand panel
• Works in a recess or as a corner end panel
• Can be used with a wetroom floor or a shower tray
• 575–590 mm adjustment helps the panel sit in the recess
• Lifetime guarantee covers the panel

Technical Specifications

• MPN: S10SW600H
• Size: 600 mm
• Glass height: 2000 mm
• Height including rail: 2015 mm
• Glass thickness: 10 mm
• Glass: Toughened
• Glass finish: Clear
• Colour: Chrome
• Minimum opening: 500 mm
• Handing: Reversible
• Installation: Recess or corner
• Application: Wetroom and shower tray
• Guarantee: Lifetime

What’s in the Box?

• 1 x 600 mm shower wall panel
• 1 x wall profile
• 1 x straight stabilising bar
