Merlyn AHI12BGM 1200mm Brushed Gun Metal Hinge And Inline Screen

The Merlyn AHI12BGM is an ARYSTO Sleek hinge and inline shower screen, 1200 mm wide and 1950 mm high, in brushed gun metal with 8 mm clear glass.

It is handed reversible, so it can be fitted for left- or right-hand opening in a domestic bathroom, whether as a new install or a replacement. Adjustment is 1150–1190 mm in a recess and 1153–1193 mm when used with a side panel.

The moving panel is 630 mm and the fixed inline panel is 495 mm, with a 600 mm door opening in either arrangement.

Key Features

• 1200 mm ARYSTO Sleek hinge and inline screen
• 1950 mm high
• 8 mm clear glass
• Brushed gun metal finish
• Reversible handing
• 1150–1190 mm adjustment in a recess
• 1153–1193 mm adjustment with a side panel
• 600 mm door opening in recess or with a side panel
• 630 mm moving panel and 495 mm fixed panel
• Lifetime guarantee

Benefits

• Gives a walk-in style opening with a hinged door and a fixed inline panel
• Brushed gun metal finish suits contemporary bathrooms
• Clear 8 mm glass keeps the enclosure bright
• Reversible handing avoids ordering a left- or right-hand version
• Recess adjustment covers a 40 mm fitting range
• Can also be used with a side panel within a stated adjustment range
• 600 mm door opening in both installation arrangements
• Lifetime guarantee for long-term peace of mind

Technical Specifications

• MPN: AHI12BGM
• Model: ARYSTO Sleek
• Size: 1200 mm
• Height: 1950 mm
• Glass thickness: 8 mm
• Glass finish: Clear
• Colour: Brushed Gun Metal
• Handing: Reversible
• Adjustment in recess: 1150-1190 mm
• Adjustment with side panel: 1153-1193 mm
• Door opening in recess: 600 mm
• Door opening with side panel: 600 mm
• Door / panel swing: 630 mm
• Moving panel: 630 mm
• Fixed panel: 495 mm
• Guarantee: Lifetime

What’s in the Box?

1 x Merlyn AHI12BGM ARYSTO Sleek hinge and inline 1200 shower screen
