Bristan TAN 1HBF BB Tangram 1 Hole Bath Filler Brushed Brass

The Bristan Tangram 1 Hole Bath Filler (TAN 1HBF BB) features geometric lines and a beautifully tapered spout in a warm brushed brass finish, ideal for modern bathrooms. Robust metal fixings ensure secure installation.

Key Features

• Supplied with flexible tails for hassle-free installation
• Robust metal fixing nut for secure, reliable mounting
• Long-life ceramic cartridge for smooth operation and durability
• Brushed brass finish
• Lifetime parts guarantee with 1-year labour
• WRAS approved
• Manufactured from brass

Specifications

• Minimum operating pressure: 1.0 bar
• Maximum operating pressure: 5.0 bar
• Maximum static pressure: 10 bar
• Maximum hot water temperature: 60°C
• Tap height: 160 mm
• Spout reach: 100 mm
• Base to spout: 110 mm
• Inlet connection: 1/2 inch
• Outlet: M24 recessed honeycomb aerator
• Flow rate at 1.0 bar: 15 l/min
• Flow rate at 2.0 bar: 21.1 l/min
• Flow rate at 3.0 bar: 25.2 l/min
• Flow rate at 5.0 bar: 34.2 l/min

Applications

Suitable for all plumbing systems. Pillar mounted for 1 tap hole baths. Waste sold separately.

What’s in the box

Tap body, flexible tails, fixings and ceramic cartridge.
